Navigator Li330 Integrated Air Floor Inflatable 10'9" Boat

Enjoy effortless transport and quick setup wherever your journey takes you with the Navigator Li330 integrated Air floor inflatable boat—a dependable sailboat tender and versatile dinghy. Built for stability and reliability, it navigates lakes, rivers, and calm seas with ease.

The Navigator is made in Europe and built for big rivers and lakes. Its standout design feature is a set of U-shaped cylinders with a variable diameter that gradually decreases from the stern to the bow. Thanks to its raised (“chiselled”) bow and smoothly curved hull (rather than sharp angles), Navigator inflatable boats can reach planing mode even with smaller engines—while also being less likely to snag on rocks or slam into oncoming waves.

Navigator models are engineered for peak performance, much like today’s mobile devices are designed to maximize efficiency. They use marine-grade plywood flooring sealed with extra layers of waterproof varnish instead of heavier aluminum floors, which can oxidize relatively quickly. The result: more usable payload capacity, easier setup, and simpler transport.

Among the lineup, the Navigator Li330—featuring an inflatable bottom—has long been a flagship model, alongside the Air360.

Features

☑ Original Designs of Cylinders
Boats built by Navigator are both beautiful and reliable.

☑ Heat Welding Technology
Navigator Inflatable Boats seams are 100% fully heat welded.

☑ Modern Five Layered PVC
Navigator inflatable boats are made from materials that can withstand all conditions and provide you with years of enjoyment.

☑ Improvements in Hydrodynamic Contours
The Navigator boat’s hydrodynamic contours provide an unmatched experience in terms of ride quality.

☑ Floating on marine-grade, waterproof plywood
Navigator flooring system is uniquely designed for inflatable boats.

☑ Added Reinforcement to the Transom
Navigator reinforced transoms are made of durable, water-resistant plywood.

☑ Full Quality Control
At Navigator, we developed technologically advanced processes, designed and manufactured special equipment, studied materials for future Navigator boats.

☑ It exhibits pronounced keel characteristics similar to the Li360 model.
☑ The balloons have a diameter of 48 cm and a width of 185 cm.
☑ Hardware used: Ukrainian-made.
☑ PVC material primarily sourced from Taiwan, South Korea, and Germany.
☑ Utilizes heat welding technology.
☑ Confident glider performance with one person weighing 90-100 kg is possible with motors ranging from 6 to 8 hp. The captain’s position in such models is closer to the center.
☑ The optimal motor for this model is 9.8 hp to 15 hp.
☑ The PVC boat weighs approximately 50 kg, with seats, oars, a pump, and a repair kit weighing 8 kg.
☑ During transportation, it can easily fit in the trunk or on the rear seat of a lightweight car.
☑ This inflatable bottom boat model is certified for compliance with EU standards.

Standard Navigator Inflatable Boats Construction Elements

Specifications

☑ Type of bottom: Inflatable (keel)
☑ External length : 129.92 inches
☑ External width : 70.87 inches
☑ Internal length : 90.55 inches
☑ Internal width : 30.71 inches
☑ Tube diameter : 18.90 inches
☑ Number of sealed compartments: 3+1
☑ Load capacity : 1322.77 pounds
☑ Passenger capacity, persons: 4
☑ Recommended motor power, hp: 10 horsepower
☑ Maximum motor power, hp: 15 horsepower
☑ Cylinder material density, g/m2: 1100 (South Korea)
☑ Bottom material density, g/m2: 1100 (South Korea)
☑ Transom height : 16.14 inches, including the bottom
☑ Transom thickness : 0.94 inches
☑ Transport handles, pieces: 2 at the ends
☑ Oar length : 70.87 inches
☑ Oarlocks type: Swivel, pin type
☑ Boat bag size : 53.15 x 15.74 x 19.69 inches
☑ Warranty for welded seams, months: 60 months
☑ Warranty for PVC material, months: 36 months
☑ Warranty for inflatable bottom, months: 24 months

Standard kit Navigator Roll-up Boats

☑  2 Oars with oarlocks
☑ Towing handle under the bow
☑ 2 Movable Seats
☑ Anchor mount D-ring with a rubber bow protector for the rope
☑ Book-type wooden floor. Floorboards are connected with PVC strips, easy to install &
store (alternative floors: slatted, hard deck wood or aluminum, inflatable floor).
☑ Small repair kit (Patch, glue, valve unscrew tool)
☑ Efficient Foot pump
☑ 2 Bags to carry the boat & the floor

Navigator Inflatable Boats Warranty

User Manual

How to Assemble Inflatable Boats?

Frequently Asked Questions

☑ What is an inflatable boat used for?
Consider inflatables for versatile recreational boating activities like fishing, duck hunting, camping, surfing, or sightseeing. However, be mindful of your needs and avoid rough waters with smaller models. Some heavy-duty inflatable rafts are also used by law enforcement and military personnel.
☑ Do I have to register my inflatable boat?
If you installed an outboard motor of 10HP or more, you may need to register your new vessel. Navigator Inflatable Boats have a unique HIN registered with Transport Canada, which is recognized in the US under a bilateral agreement.
☑ Do I need a boating license for an inflatable boat?
To operate an inflatable boat with a motor, you need a pleasure craft operator license. For fishing, you may also need extra licenses and permits, depending on your location. Check the List of Accredited Service Providers for more information.
☑ How do you repair or patch up holes in my inflatable boat?
The Standard Navigator roll-up boat comes with a patch kit. A small repair kit will consist of a valve unscrew tool, glue and PVC patches. For complex boat repairs, talk to a professional technician. For additional boat guides, check the “Repairs” section of the Navigator Inflatable Boats User Manual.
☑ How many people does my inflatable boat fit?
It’s all about the right boat size, how much weight it can handle, and some design features. Typical inflatable boats can seat a maximum weight of 2 to 6 people. Here are some currently available options:
*2 Passenger inflatable boat
Navigator’s LG-series
*2 – 3 Person Inflatable Boat
Navigator LP-series
*4 Person Inflatable Boat / 6 Person Inflatable Boat
Navigator LK-series
☑ What inflatable boat should I choose for different types of waters?
Choose a smaller, maneuverable boat for lakes and flat water rivers, and a larger vessel with a powerful engine and keel for open ocean. Consider comfort with ample space and seating for longer trips.
☑ Which parts should I be outfitting my boat with?
Attach a boat engine for faster transportation, add an extra hull for added safety and more seating, use a boat ladder for water activities like swimming, diving, or water skiing, and get seats for comfort. For fishermen, invest in fishing rod holders.
